Vacuum Type Oil Seal Trimming Machine |
|
| OPERATION |
| This machine is used for cutting the
edges of soft objects such as oil seals, soft rubber parts and U
packing. |
| 1. |
Manual feed and
auto trim. |
| 2. |
Cuts the bevel
angle of plain face, inner & outer bevel angle simultaneously. |
| 3. |
Auto product blow off by air cylinder. Flash separator separates finished oil seals and flash to save time. |
| 4. |
Adjust the position for the cross slide and the angle meter plate to the appropriate position for cut range and angle adjustment. |
| 5. |
Number of cutters, inverters, flash separator, and blowing plates by customer request. |
MODEL |
NR-100 |
NR-200 |
NR-400 |
| Weight (kgs) |
280 |
280 |
350 |
| Dimensions (cm) |
90(L) × 90(W) × 190(H) |
90(L) × 100(W) × 190(H) |
100(L) × 100(W) × 190(H) |
| Cutting range (mm) |
O.D. 8
-100 |
O.D. 100
-200 |
O.D. 200
-400 |
Spindle speed (rpm) |
2800 |
Adjustable |
Adjustable |
Capacity (pcs/min) |
12-20 (Approx.) |
10-15 (Approx.) |
6-10 (Approx.) |
Tooling pad size (mm) |
φ 32 or φ 79 |
φ 25 or φ 79 |
φ 25 or φ 79 |
| Left cutting angle |
30° - 70° |
| Right cutting angle |
0° - 90° |
Cutting speed |
2 stages, adjustable |
Number of cutters |
1~3 |
Cutter size (mm) |
3×3 , 3×1.8 , 5×1.8 |
Motor |
1/2 HP |
2 HP |
2HP |
Clutch brake |
1kg single-flange solenoid |
4kg single-flange solenoid |
4kg single-flange solenoid |
Inverter |
× |
ˇ |
ˇ |
| Scrap separator |
ˇ |
x |
x |
Blowing plate |
ˇ |
x |
x |
| Controller |
PLC +
Air cylinder |
|
|
|
